Chapter 2: Installation 19
2.6 System Check and Initial Switch On
When installation is complete and all connections have been made, re-
check the installation before using the system for navigation. If problems
occur, refer to Chapter 6:Maintenance & Troubleshooting.
EMC Conformance
Always check the installation before going to sea to make sure that it is
not affected by radio transmissions, engine starting, etc.
System Check
Before performing the functional test, check that:
• All connections are clean and tight
• All cables are secured and protected
Initial Switch On
To switch on the chartplotter, press the POWER key.
If necessary, adjust the lighting and contrast (see Chapter 4).
If desired, change the default language settings as follows:
1. Press the PAGE key to display the setup function bar.
2. Using trackpad left/right, select the SYSTEM SET UP f un c ti on and pr e ss
ENTER. The SYSTEM SET UP m e nu i s d is pl a ye d, l i st in g th e p a ra me te rs
and their current settings:
Figure 2-4: System Set Up Menu
SYSTEM SET UP
KEY BEEP
DISTANCE UNITS
DEPTH UNITS
VARIATION
ON
nm
FEET
5°W
BEARING MODE
TRUE
SPEED UNITS KNOTS
DATE FORMAT
TIME OFFSET
SIMULATOR
SIMULATED SOG
MM/DD/YY
UTC
OFF
5.0 KTS
VARIATION MODE AUTO
LANGUAGE
ENGLISH
SIMULATED COG 340°T
D6247-3
To Next Page
