Raymarine SmartPilot X-5R User Manual

4 SmartPilot X-5R Drive Installation and Setup Guide
1.3 Equipment & Tools
Before you begin ensure you have all the necessary components and tools to install
your system.
Parts supplied
D10662
3 mm allen key
Pan head screw,
No 8 x 3/4 inch (x7)
Countersunk screw,
M5 x 12 (x4)
Sun
cover
SmartPilot
ST6002
controller
Panel
seal
Cable tie
(x12)
Spade
connector
(1/8" x 2)
Spade
connector
(1/4" x 1)
Stud (x2)
Finger nut (x2)
5/8 inch,
Nyloc nut
M4
nut (x4)
M4
washer (x4)
M4 spring
washer (x4)
Countersunk screw,
M4 x 25 (x4)
5/8 inch
seal washer
Taper
adaptor
Woodruff
key
Woodruff
key (standard)
Stub shaft
SeaTalk cable,
4 m (13 ft)
Course
computer
Drive unit
Compass
warning label
Fluxgate compass
with 8 m (26 ft) cable
User documents
in wallet
Box
spanner
