Raymarine SmartPilot X-5R User Manual

Chapter 4: SmartPilot X-5R Drive Settings 55
.
Vessel type
Selecting the correct vessel type, enables the SPX-5R Drive system to set
appropriate values for other calibration settings, to give optimum performance. Refer
to the table on page 60 for default values.
Options Vessel type
DISPLACE Power-driven boats which do not plane
(Typically below 15 kts top speed)
SEMI DISPLACE Faster power-driven boats which do not plane
(Typically 15-20 kts top speed)
PLANING Planing boats with inboard engine(s) and shaft drives
(NOT boats with outdrives)
Accessing
Dealer Calibration
Dealer Calibration
D10470-1
To exit & save changes
2 seconds
2 seconds
(saves changes)
+
or
or
To adjust values
