Chapter 3: Commissioning & Setup 47
To adjust the AutoTrim
1. Enter Dealer calibration as described on page 35.
1. Use
disp
as necessary to access the
AUTOTRIM
screen.
2. Use
-1
or
+1
to adjust the AutoTrim level.
3. Press and hold
standby
for 2 seconds to save the changes and leave Dealer
calibration.
4. Press
auto
to check the SPX-5R Drive system performance in Auto mode.
Rudder damping
If a rudder reference transducer is fitted, you can set the SPX-5R Drive system rudder
damping to prevent autopilot ‘hunting’, i.e. continuously moving the steering
backwards and forwards by small amounts. To set up the rudder damping:
1. Enter Dealer calibration as described on page 35.
2. Use
disp
as necessary to access the
RUDD DAMP
page.
3. Use
-1, +1, -10
and
+10
to set the rudder damping so the hunting stops. Use the
lowest rudder damping value at which hunting stops.
4. Hold down
standby
for 2 seconds to save the changes and leave Dealer
calibration.
