Chapter 1: Installation and system overviews 5
Tools and equipment NOT supplied
You will need to supply the following equipment and tools:
Tools:
Flat bladed screwdriver
Power drill (cordless recommended).
Bearing puller (optional - to remove the steering wheel).
5
/
32
in (4 mm) drill.
Suitable wrenches/spanners.
Cables / equipment
Power cable and fuse/breaker. See page 20.
Additional data cables (e.g. for connection of GPS or chartplotter).
Grounding braid. See page 25.
1.4 Create a schematic diagram
As part of the preparation for installing your SPX-5R Drive system, we recommend
that you create a schematic diagram representing the system you want to install. This
will help ensure that you install a safe optimum system, and so is particularly
important if you intend connecting your autopilot to other electronic equipment.
The schematic diagram should include:
Location of all components. See page v and page 7 for EMC guidelines that may
affect the location of specific components.
Connectors, cable types, routes and lengths.
When you have completed the schematic diagram, you are ready to begin installing
the SPX-5 Drive system.
