REPLIGEN KrosFlo KR2i User Manual

10
DOC0304
eRev. [Major Version]1.01.0 8/9/2023
User Guide
KrosFlo® KR2i Real-Time Process Management (RPM™) System
Table 5. Physical Specifications
Specification Value
KR2i Main Pump
Dimensions (L × W × H)
10.5 in × 8 in × 8 in
(267 × 203 × 203 mm)
Weight 13 lb. (5.9 kg)
KR2i Pump Heads
Mounted dimensions (W x H x D) 8.8 cm x 12.1 cm x 7.8 cm (3.45" x 4.75" x 3.08")
Weight 1.1 lb (0.5 kg)
Housing Materials Glass-filled polypropylene (PP), polyphenylene sulfide (PPS), nylon (PA)
Roller Material Stainless Steel
Bearing Material Sealed Stainless Steel
Rotor material Stainless Steel
FlowVPX Instrument
Dimensions (L × W × H)
4” x 4¾” x 9”
(102 x 121 x 229 mm)
Weight
4.31 kg (with 3 mm Flow Cell)
4.22 kg (with 10 mm Flow Cell)
5.54 kg (with 22 mm Flow Cell)
Delivery Fiber Optic Cable Length 3 m (Optional 6 m Fiber Available Upon Request)
Cary 60 Spectrophotometer
Dimensions
22" x 19" x 8"
(559 x 483 x 203 mm)
Weight 18.14 kg
KONDUiT Conductivity, Temperature, and UV Monitor
Dimensions (L × W × H) 7 ¾” x 4 ¾” x 4½”
KR2i TFF System
Supply voltage limits 90–260 V
RMS
@ 50–60 Hz (Universal Input)
Current, Maximum 2.2 A @ 115 V
RMS
, or 1.1 A @ 230 V
RMS
FlowVPX System
Supply voltage limits 100–230 VAC @ 50–60 Hz
Current, Maximum 0.6 A
Cary 60 Spectrophotometer
Voltage 100–240 VAC
Input Frequency 47–63 Hz
KONDUiT Conductivity, Temperature, and UV Monitor
Voltage 24 VDC
Current 0.625 A
