4. Remove the spring from the left end [A] and right end [B] to prevent the springs from getting lost.
• If you are replacing the transfer roller, save these springs. New springs may not be provided
with the new transfer roller.
Re-installation
1. Clean the charge plates [A] on the side where the left end of the roller will be re-installed. The
spring will be re-attached over the peg [B].
Paper Feed and Exit
95

Ricoh Aficio SP 100 Specifications

General

Print Speed	13 ppm
Resolution	1200 x 600 dpi
Paper Capacity	50 sheets
Connectivity	USB 2.0
Warm-up Time	25 seconds
First Print Out Time	13 seconds
Paper Output Capacity	10 sheets
Type	Monochrome Laser Printer
Memory	16 MB
Print Technology	Laser
Supported Paper Sizes	A4, A5, A6, B5
Supported OS	Windows, Mac OS
