6. Lift the ADF.
CFF024
7. Turn the knob P, and then remove the misfed paper.
1
CFF025
1. Knob P
8. Lower the ADF.
When R is displayed (Type 3 Only)
This section describes how to remove misfeeds from location “R”.
1. Pull up on the lever to open the rear cover.
1
2
CFF012
Removing Jammed Paper
135
6

Ricoh Aficio SP 5210SR Specifications

General

Brand	Ricoh
Model	Aficio SP 5210SR
Category	All in One Printer
Language	English
