2. Operation panel ( p.24)
3. Left cover [A] ( x 3, hook at arrow mark)
• Top front screw: M3x8, others: M4x10
Front Cover Unit
1. Rear cover ( p.23)
2. Operation panel ( p.24)
3. Transfer unit ( p.48)
4. Right cover ( p.25)
5. Close the front cover [A].
4. Replacement and Adjustment
26
