12. Black AIO gear [H] (snap ring x 1)
13. ITB gear [I] (snap ring x 1)
14. Black AIO motor [J] ( x 3)
Color AIO Motor
1. Drive unit ( p.33 "Black AIO Motor")
2. Drive unit guide [A] ( x 3)
3. Color AIO gear [B] (ring stopper)
4. Replacement and Adjustment
36
4
