5. Duplex timing belt [B]
6. Left bracket [C] ( x 4)
7. Duplex motor [D] ( x 2, x 1)
EEPROM
• Replacement and Reinstallation procedures for the EEPROM are included in the "EGB (Engine Board)"
replacement procedure. Refer to "EGB (Engine Board)" for details.
When replacing an old EEPROM with a new EEPROM, EEPROM setting is required. Follow the EEPROM
setting procedure described below.
• Do the following steps 1 to 11 with the front cover of the machine open. After completing these steps,
turn off the machine.
1. Open the front cover and turn on the machine.
• The machine may issue an error code (because the cover is open), but continue this procedure.
4. Replacement and Adjustment
74
