Counter and Coverage
Configuration Page
The configuration page for the printer models has the paper jam, coverage and consumed AIO counters
in the bottom line, but these counter names are not printed on the configuration page. These counters give
the following information;
Three counters [A]: Feed jam counter, inner jam counter, duplex jam counter
Four counters [B]: Recent coverage of K, C, M, Y
Four counters [C]: Accumulated Coverage of K, C, M, Y
Four counters [D]: Consumed High Yield AIO counter of K, C, M, Y
Four counters [E]: Consumed Short Yield AIO counter of K, C, M, Y
The symbols [F] printed beside the remaining toner counter indicate the type of the AIO.
• S: Short Yield AIO
• H: High Yield AIO
5. System Maintenance Reference
80
