When reinstalling the paper exit roller
Make sure that the ground wire [A] from the discharge sheet touches the ground plate [B] on the printer
after reinstalling the paper exit roller.
Paper Exit Sensor
1. Rear cover ( p.23)
2. Right cover ( p.25)
3. Right bracket [A] ( x 3: M3x8, x 1 [B]: M4x10)
4. Replacement and Adjustment
62
4
