5.6 DIP SWITCHES
Controller: DIP SW2
DIP SW No. ON OFF
1 IC Card Boot System ROM Boot
2
3
4
Keep at “OFF”
I/O Board: DIP SW101
DIP SW No. Function ON OFF
1 Not used. Off (Do not change)
2
Jam Detection
(see Note)
Off On
3 SC Generation Disabled Enabled
4 Not used OFF (Do not change)
5 Not used OFF (Do not change)
6
7
Destination OFF Japan
OFF
ON North America
OFF
OFF Europe
ON
ON Not used
ON
8
Software
Download
Software download from IC card
for the engine.
Normal position.
NOTE: Disabling jam detection is effective only for the main machine (not for the
options).
