LASER EXPOSURE
G065
6-14
SM
6.4.5
LD SAFETY SWITCHES
To ens
ure per
sonal
safety
and to prevent th
e laser beam
f
rom i
nadv
ertently
switchi
n
g on during
servicing, pow
er to the laser diode
is switched off w
hen the
front cover
or upp
er rig
h
t cover i
s opened.
Four safety
switches are inst
alled in
series on the
LD5 V line fr
om the p
o
wer suppl
y unit (
PSU) via the BIC
U board.
CN403-1
CN403-3
CN402-4
CN312-1
CN109-8
CN301-10
+5V
PSU
BICU
LDDR
+5V
LD5V
LD1
LD2
Front Cover
Safety Switch
Upper Right
Cover Switch
G065D505.
W
MF
