Item Specifications
Number of pages supported
by memory sorting
Maximum: 2,000 pages
Copy/A4 original: Approx. 2,000 pages
Printer/A4/600 dpi, 4 bits: Approx. 2,000 pages
(Under the printer mode, the number of pages that can be sorted
depends on the print image.)
• After the documents have been stored up to the maximum, no more document can be stored.
Delete unneeded documents.
Specifications for Facsimile
This function may not be used depending on the telephone line or area status.
• To connect the machine to the network, use a LAN cable supporting 1000BASE-T, 100BASE-TX,
and 10BASE-T. The length of the usable cable is up to 100 m.
Fax Transmissions and Reception
Item Specifications
Standard G3
Resolution • Standard: 8 × 3.85 lines/mm, 200 × 100 dpi (Standard
character), 8 × 7.7 lines/mm, 200 × 200 dpi (Detail character)
• Optional: 8 × 15.4 lines/mm, 16 × 15.4 lines/mm, 400 × 400
dpi (Super Fine character)
*1
Transmission time 3 seconds at 28,800 bps, Standard resolution (JBIG transmission: 2
seconds)
Data compression method MH, MR, MMR, JBIG
*2
Maximum original size Standard: A3 or 11 × 17
Custom (w × h): 297 × 1,200 mm (11.7 × 47.3 inches)
Maximum scanning size 297 × 1,200 mm (11.7 × 47.3 inches)
Print process Laser beam scanning and electro-photographic printing
11. Specifications for The Machine
324
