Ricoh IM C3010 User Manual

Basic Scanning
179
6
7. Check the login password on the computer, and write down the information in [3] on
the check sheet.
The required information on the computer is confirmed. Now create a shared folder
on your computer and specify the access permissions of the folder.
• Depending on the operating system or security settings, it might be possible to
specify a user name that does not have a password assigned. However, we
recommend that for greater security you select a user name that has a password.
Creating a Shared Folder (Windows)
Create a shared folder on the Windows Desktop and specify the access permissions of
the folder.
1. Log on to Windows as a user with administrative privileges.
2. Create a new folder and write down the folder name in [4] on the check sheet.
3. Right-click the created folder, and then click [Properties].
4. On the [Sharing] tab, click [Advanced Sharing].

Ricoh IM C3010 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Warm-up Time	21 seconds
Paper Weight	52 - 300 gsm
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A3
Fax	Yes
Modem Speed	33.6 kbps
Mobile Printing Support	Apple AirPrint, Mopria, Ricoh Smart Device Connector
Operating Systems Supported	Windows, macOS, Linux
Dimensions (W x D x H)	587 x 685 x 788 mm
Type	Multifunction Color Printer
Print Speed	30 ppm (Black/Color)
Memory	2 GB RAM
Hard Disk Drive	320 GB
Supported Paper Sizes	A4, A5, A6, B4, B5, B6, Letter, Legal, Custom
Scan Type	ADF, Flatbed
Scanning Speed (Black/Color)	80 ipm
Scan Destinations	Email, Folder, USB
Copy Speed	30 copies per minute
Zoom Range	25% - 400%
Fax Resolution	200 x 200 dpi
Connectivity	USB 2.0, Ethernet, Wi-Fi
Power Consumption (Maximum)	1.5 kW
Control Panel	10.1" Smart Operation Panel
