Ricoh IM C3010 User Manual

1. Introduction and Basic Operations
74
1
• To scan originals larger than B4 JIS or 8
1
/
2
× 14 size, raise the ADF's
extender on the ADF output tray.
• When using the ARDF to scan originals with a paper weight less than 40.7
g/m
2
(approx. 11 lb. Bond), move the slide tray on the original output tray
to the left side. When the slide tray of the Auto Reversible Document
Feeder (ARDF) is in the left, the amount of output paper will be low. After
scanning a thin original, return the slide tray to the previous position.
Placing Originals in the One-pass Duplex Scanning ADF
• Do not block the sensors with your hand. Be sure to load the originals neatly and
do not push them into the ADF forcibly. It may cause paper misfeeds or paper
size error.
• Do not add originals while other originals are being fed.
• If you want to add the originals to the bottom of the original stack on the ADF,
remove the originals temporarily to add the new originals, and then reload the
combined stack of originals.

Ricoh IM C3010 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Warm-up Time	21 seconds
Paper Weight	52 - 300 gsm
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A3
Fax	Yes
Modem Speed	33.6 kbps
Mobile Printing Support	Apple AirPrint, Mopria, Ricoh Smart Device Connector
Operating Systems Supported	Windows, macOS, Linux
Dimensions (W x D x H)	587 x 685 x 788 mm
Type	Multifunction Color Printer
Print Speed	30 ppm (Black/Color)
Memory	2 GB RAM
Hard Disk Drive	320 GB
Supported Paper Sizes	A4, A5, A6, B4, B5, B6, Letter, Legal, Custom
Scan Type	ADF, Flatbed
Scanning Speed (Black/Color)	80 ipm
Scan Destinations	Email, Folder, USB
Copy Speed	30 copies per minute
Zoom Range	25% - 400%
Fax Resolution	200 x 200 dpi
Connectivity	USB 2.0, Ethernet, Wi-Fi
Power Consumption (Maximum)	1.5 kW
Control Panel	10.1" Smart Operation Panel
