4. Configuration
This chapter explains supported network connections, and settings for the IP addresses and the Wireless
LAN security.
Ethernet Configuration
Configure the following network settings according to the network environment using the control panel.
• The following table shows the control panel settings and their default values. These items appear in
the [Host Interface] menu.
Setting Name Default
Machine IPv4 Address
• DHCP: On
• IPv4 Address: 11.22.33.44
• Subnet Mask: 0.0.0.0
• Gateway Address: 0.0.0.0
IPv6 Stateless Setting Active
IPsec Inactive
NW Frame Type Auto Select
Effective Protocol
• IPv4: Active
• IPv6: Inactive
• NetWare: Inactive
• SMB: Active
• AppleTalk: Inactive
Ethernet Speed Auto Select
IEEE802.1X Auth.(Ethernet) Inactive
Restr.IEEE802.1X Auth.Def. -
LAN Type Ethernet
• If DHCP is in use on your network, the IP address, subnet mask, and gateway address are all set
automatically.
63
