GENERAL REMARKS
15
Menu
Parame-
ters
Scrolling message
only if parameter P1.05 = 1
Value
Password
level
Value set
in the factory
Personali-
sed
values
P1 SETTINGS
P1.01
LANGUAGES
0 IT
1 RO
2 FR
3 EN
4 SR
5 HR
6 ES
7 EL
8 BG
9 PL
10 SL
USER
P1.02
TIME
USER
P1.03
TIME PROGRAM NOT AVAILABLE
P1.05
SCROLLING 0 / 1
USER
0
P3 CONFIGURATION
P3.01
HYDRAULIC CONFIGURATION 0 / 1 / 2 / 3 / 4 INSTALLER 0 (°)
P3.02
WATER PRESSURE TRANSDUCER 0 / 1 SERVICE 1
P3.03
AUTO FILL ENABLE 0 / 1 SERVICE 0
P3.04
BEGIN SYSTEM FILLING NOT AVAILABLE ON THIS MODEL
P3.05
AIR PURGING CYCLE 0 / 1 SERVICE 1
P3.06
MIN FAN SPEED 1.200-3.600 INSTALLER
see technical data
table
P3.07
MAX FAN SPEED 3.700-9.999 INSTALLER
see technical data
table
P3.08
SLOW IGNITION ADJUSTMENT MIN-MAX INSTALLER
see technical data
table
P3.09
MAX FAN SPEED HTG MIN - MAX INSTALLER
see technical data
table
P3.10
RANGE RATED NOT AVAILABLE ON THIS MODEL
P3.11
CONFIG AUX 0 / 1 / 2 INSTALLER 0
P3.12
EXHAUST PROBE RESET 0 / 1 INSTALLER 0
P3.13
IGNITION SPEED IN RESTART
AFTER SHUTDOWN DUE TO
TEMPERATURE
MIN FAN SPEED/ SLOW IGNITION
ADJUSTMENT
INSTALLER
min value between
3.600 rpm and P308
P4 HEATING
P4.01
HYST OFF HIGH TEMP 2 - 10 SERVICE 5
P4.02
HYST ON HIGH TEMP 2 - 10 SERVICE 5
P4.03
HYST OFF LOW TEMP 2 - 10 SERVICE 3
P4.04
HYST ON LOW TEMP 2 - 10 SERVICE 3
P4.05
PUMP CONTROL TYPE 60 - 100 INSTALLER 85
P4.08
OT+ CASCADE CONTROL NOT AVAILABLE ON THIS MODEL
P4.09
SCREED FUNCTION 0 / 1 INSTALLER 0 ( boiler in OFF and P4 .15=1)
P4.10
ANTI CYCLE FUNCTION 0 - 20 min INSTALLER 3 min
P4.11
RESET CH TIMERS 0 / 1 INSTALLER 0
P4.12
MAIN ZONE ACTUATION TYPE 0 / 1 INSTALLER 0
P4.13
MAIN ZONE BE16 ADDRESS 1 - 6 INSTALLER 3
P4.14
MAIN ZONE HYDRAULIC CONF 0 / 1 INSTALLER 0
P4.15
MAIN ZONE LOW TEMP 0 / 1 INSTALLER 0
P4.16
MAX CH SET
HT: MIN CH SET - 80
LT: MIN CH SET - 45,0
INSTALLER
80
45,0
P4.17
MIN CH SET
HT: 20 - MAX CH SET
LT: 20 - MAX CH SET
INSTALLER
40
20
The following table lists the programmable parameters; if the adjustment board does not support the relative func-
tion, the interface returns an error message.
1.13 Structure menu
For a detailed explanation of the parameters, refer to paragraph “1.14 Description of the parameters”.
HT = HIGH TEMPERATURE ● LT = LOW TEMPERATURE
(°) 0 = HEATING ONLY - 1 = INSTANTANEOUS BOILER WITH FLOW SWITCH - 2 = INSTANTANEOUS BOILER WITH FLOW METER -
3 = STORAGE TANK WITH PROBE - 4 = STORAGE TANK WITH THERMOSTAT
