Rigol DS1000B Series Service Guide

RIGOL Chapter 1 Specifications
DS1000B Service Guide
1-4
Set Level to 50%
(Typical)
Input signal frequency ≥50Hz
Edge Trigger
Edge Type
Rising, Falling, Rising + Falling
Pulse Trigger
Trigger Condition
(
＞
,
＜
, =) positive pulse, (
＞
,
＜
, =) negative pulse
Pulse Width Range
20ns to 10s
Video Trigger
Video Standard&Line
Frequency
Support standard NTSC, PAL and SECAM broadcast
standards. The range of the number of lines: 1 to 525
(NTSC) and 1 to 625 (PAL/SECAM)
Pattern Trigger
Pattern Setup
H, L, X, ,
Alternate Trigger
CH1, CH2, CH3, CH4
Edge, Pulse, Video
Measurement
Cursor
Manual
Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
Track
Voltage value and time value of waveform
point
Auto
Cursors can be displayed in auto
measurement
Auto Measure
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms,
Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time,
+Width, -Width, +Duty, -Duty, Delay A→B
, Delay A→
B
，Phase A→B ,Phase A→B
Note:
[1] Half channel indicates selecting one of CH1 and CH2, or one of CH3 and CH4.
[2] This is the highest specification for the highest model. The specific equivalent sample rate of
each model is as follows.
DS1204B: 50GSa/s
DS1104B: 25GSa/s
DS1074B: 10GSa/s
