Chapter 3 Performance Test RIGOL
DS1000B Sevice Guide
3-7
Impedance Test
Specification:
Input Impedance
Analog Channel (CH1 to CH4)
1 MΩ: 0.98 MΩ to 1.02 MΩ
Test Procedures:
1. Impedance test of CH1 to CH4
1) Connect the active signal terminal of Fluke 9500B to CH1 of the oscilloscope,
as shown in Figure 3-8.
2) Configure the oscilloscope:
a) Press CH1 in the vertical control area (VERTICAL) at the front panel to
turn on CH1.
b) Rotate VERTICAL SCALE to set the vertical scale of CH1 to 100
mV/div.
3) Turn on Fluke 9500B; set its impedance to 1 MΩ and select the resistance
measurement function. Read and record the resistance measured.
4) Rotate VERTICAL
SCALE to adjust the vertical scale of CH1 of the
oscilloscope to 500 mV/div; read and record the resistance measured.
5) Turn off CH1. Repeat the steps above to test the impedances of CH2, CH3
and CH4 and record the measurement results.
2. Impedance test of the [EXT TRIG] channel
1) Disconnect the connections of the four input channels.
2) Connect the external trigger channel [EXT TRIG] with the active signal
terminal of Fluke 9500B.
3) Turn on Fluke 9500B; set its impedance to 1 MΩ and select the resistance
measurement function. Read and record the resistance measured.
Test Record Form:
CH1 to CH4
Channel Vertical Scale Test Result Limit Pass/Fail
CH1
100 mV/div
0.98 MΩ to 1.02 MΩ
500 mV/div
CH2
100 mV/div
500 mV/div
CH3
100 mV/div
500 mV/div
CH4
100 mV/div
500 mV/div
External Trigger Channel
Channel
Input Impedance
Test Result
Limit
Pass/Fail
EXT TRIG 1 MΩ 0.98 MΩ to 1.02 MΩ
