Chapter 5 Disassemble and Assemble RIGOL
DS1000B Sevice Guide
5-3
Structure Diagram
Figure 5-1 DS1000B Stereogram
Probe
Compensator
Handle
Function
Key
Vertical Control
Power Switch
USB Host
Interface
Multi-Function Knob
Running
Control
Analog
Signal Inputs
External
Trigger Input
Horizontal Control
Trigger
Control
