RIGOL Chapter 2 To Prepare for Use
DS1000B Service Guide
2-4
To Connect the Probes
DS1000B series digital oscilloscope provides four channel inputs and an external
trigger input.
Please take the following steps to connect the probes.
1. Connect the BNC connector of the probe to the channel input or external trigger
interface. Insert the BNC connector into the interface vertically and turn it
clockwise.
Figure 2-3 BNC Interface Connection
2. Connect the other end of the probe to the circuit under test.
Figure 2-4 Circuit Under Test Connection
3. Disconnect the circuit when the test is finished. Turn the BNC connector of the
probe anticlockwise and pull it out vertically.
WARNING
When using 10:1 probe, don’t input a signal with a voltage higher than the
maximum input voltage.
