Rigol DS1000B Series Service Guide

Chapter 1 Specifications RIGOL
DS1000B Service Guide
1-5
General Specifications
Display
Display Type
5.7 inch (145 mm diagonal line) TFT LCD
Display Resolution
320 horizontal × RGB × 240 vertical pixels
Display Color
64k color
Contrast (Typical)
150:1
Backlight Brightness (Typical)
300 nit
Probe Compensator Output
Output Voltage (Typical)
Approximately 3Vpp (peak-peak value)
Frequency (Typical)
1kHz
Power
Power Voltage
100 to 240 VAC, 45 to 440Hz, CAT II
Power Consumption
Less than 50W
Fuse
2A, T rating, 250 V
Environmental
Ambient Temperature
Operating: +10
℃
to +40
℃
Non-operating: -20
℃
to +60
℃
Cooling Method
Fan force cooling
Humidity
+35
℃
or below: ≤90% relative humidity
+35
℃
to +40
℃
: ≤60% relative humidity
Altitude
Operating 3,000 m or below
Non-operating 15,000 m or below
Mechanical
Diemnsions
Width
325mm
Height
159mm
Depth
133 mm
Weight
Without package
3kg
With Package
4.3kg
IP Protection
IP2X
Calibration Interval
The recommended calibration interval is one year
