Chapter 5 Disassemble and Assemble RIGOL
DS1000B Sevice Guide
5-5
To Disassemble and Assemble the Upper Metal
Cover
Figure 5-3 To Disassemble and Assemble the Upper Metal Cover
Part Explanation:
③ 8 screws (M3*6 countersunk head torx machine screw) at the upper cover.
Disassemble step:
1. Remove the 8 screws (③) using the screwdriver (T10). Remove the upper cover.
③
③
③
③
③
③
③
③
Upper Cover
