Amplitude
Setting Range
Specification level
range
Setting range
Maximum
output level
[1]
9 kHz ≤ f < 100 kHz
+5 dBm
100 kHz ≤ f ≤ 3 GHz
+13 dBm
+20 dBm
Minimum
output level
9 kHz ≤ f ≤ 100 kHz
-110 dBm
100 kHz < f ≤ 3 GHz
-110 dBm
-110 dBm
Setting
resolution
0.01 dB
Absolute Level Uncertainty
Level
uncertainty
Temperature range: 20℃ to 30℃
+13 dBm to -60
dBm
-60 dBm to -110
dBm
100 kHz ≤ f ≤ 3 GHz
≤ 0.9 dB,
≤ 0.5 (typ.)
≤ 1.1 dB,
≤ 0.7 (typ.)
VSWR
[2]
1 MHz ≤ f ≤ 3 GHz
< 1.8 (typ.)
Level Setting
Setting time
[3]
Fixed frequency,
temperature range:
20℃ to 30℃
≤ 5 ms (typ.)
Max. Reverse Power
Max. reverse
power
Max. DC voltage
50 V
1 MHz < f ≤ 3 GHz
1 W
Note: [1] Typical maximum output level up to +20 dBm (±1 dB) when output frequency ≥ 10 MHz.
[2] 50 Ω measurement system, typical value, output level ≤ -10 dBm.
[3] Time from receipt of SCPI command or trigger signal to within 0.1 dB of final level.
