RIGOL Chapter 6 Specifications
6-2 DSG800 User's Guide
Technical Specifications
Frequency
Frequency
DSG815
DSG830
Frequency range
9 kHz to 1.5 GHz
9 kHz to 3 GHz
Frequency
resolution
0.01 Hz
Setting time
[1]
<10 ms (typ.)
Frequency Band
Band
Frequency range
N
[2]
1
f < 227.5 MHz
0.25
2
227.5 MHz ≤ f < 455 MHz
0.125
3
455 MHz ≤ f < 910 MHz
0.25
4
910 MHz ≤ f < 1820 MHz
0.5
5
1820 MHz ≤ f ≤ 3000 MHz
1
Internal Reference Frequency
Reference
frequency
10 MHz
Temperature
stability
In temperature range 0
℃
to 50℃, reference to 25℃
< 2 ppm
With option OCXO-B08
< 5 ppb
Aging rate
< 1 ppm/year
With option OCXO-B08
< 30 ppb/year
Internal reference
frequency output
Frequency
10 MHz
Level
+5 dBm to +10 dBm
External reference
frequency input
Frequency
10 MHz
Level
0 dBm to +10 dBm
Maximum deviation
±5 ppm
Note: [1] Time from receipt of SCPI command or trigger signal to within 0.1 ppm of final frequency (final
frequency ≥ 227.5 MHz) or within 100 Hz (final frequency < 227.5 MHz).
[2] N is a factor used to help define certain specifications within the manual.
