To Set the Amplitude Parameters
Amplitude
Set the RF output amplitude.
Press LEVEL, use the numeric keyboard to input the amplitude value and select the
desired unit from the pop-up unit menu.
 The amplitude units available are dBm, -dBm, mV, uV and nV.
 You can press Backspace to delete the number at the left of the cursor.
 You can press the left/right direction key to enter the parameter editing state
and move the cursor to the specified digit; then, rotate the knob to modify the
value.
 You can also rotate the knob to modify the amplitude at the current step.
 You can press LEVEL and then press Step to set the step.
Flatness Calibration
The flatness calibration function can adjust the RF output amplitudes corresponding
to the frequency points within the frequency range of the instrument to compensate
for the external loss caused by the cables, switches or other devices. You can load
the flatness calibration lists stored in the internal or external memory to DSG800 and
view the list contents.
1. Set the flatness calibration status
Press LEVEL  Flatness  Switch to turn "On" or "Off" the flatness
calibration function. When the flatness calibration function is turned on, the UF
status label is displayed in the amplitude area of the user interface.
2. Flatness calibration list
Press LEVEL  Flatness  Cal List to enter the flatness calibration list menu.
 Load a list
Press Load to open the store and recall interface. At this point, you can
select and read the flatness calibration list files stored. For the detailed
operations, refer to "
Store and Recall". After a list is loaded, the storage
directory of the file loaded is displayed in View.
The format of the calibration list file loaded is as shown in the table on the
next page.
