Chapter 2 Front Panel Operations RIGOL
DSG800 User's Guide 2-5
SN
Freq
Level
[1]
1
207.854 000 00 MHz
-70.50 dB
2
304.000 000 00 MHz
7.45 dB
3
800.000 000 00 MHz
-17.80 dB
Note
[1]
: Amplitude calibration value. When calibrating the amplitude of the current
frequency point, only the actual output amplitude will be affected and the amplitude
display value will not change.
 View the list
You can press View to view the information of the flatness calibration list
currently loaded. Pressing any key (except the direction keys and knob) at
the front panel will return to the flatness calibration list menu.
Note: This menu is only valid after a list file is loaded.
Amplitude Unit
Set the unit of the RF output amplitude.
Press LEVEL  Level Unit and select the desired unit from the pop-up unit menu.
The output amplitude units available are dBm, dBmV, dBuV, Volts and Watts. Wherein,
dBm, dBmV and dBuV are logarithmic units; Volts and Watts are linear units. The
default is dBm.
