Front Panel Overview
The front panel of DSG800 series RF signal generator is as shown in the figure below.
You can click the number in the figure to view the corresponding introduction.
1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
Figure 1-4 Front Panel
1. Restore to Preset Key
Restore the instrument to the preset state (the factory
default state or user-stored state). For the detailed
information, refer to "
Reset".
2. LCD
3.5 inch TFT high-resolution (320×240) color LCD. The
current settings and state of the instrument can be clearly
displayed. For the detailed information, refer to "
User
Interface".
