Rinstrum - 5200 Communications Manual Rev 1.2
0025-605-120 Page 13
2.4.4. BDR: Set Baud Rate
This is used to set the communication parameters, baud rate, parity, etc.
General Details
No. of Parameters Save Changes Changes Used Increment Trade Counter
8 With TDD1 Immediately No
Parameter Details
Parameter Description Range Default Required
1 Port 0
1
Serial 1
Serial 2
- Yes
2 Baud Rate 0
1
2
3
4
5
6
300
600
1200
2400
4800
9600
19200
5 No
3 Parity 0
1
2
None
Odd
Even
0 No
4 Data bits 7,8 8 No
5 Stop bits 1,2 1 No
6 Termination
Resistors
0
1
OFF
ON
0 No
7 RS-232/
RS-485
(Serial 1 only)
0
1
RS-485
RS-232
0 No
8 CTS
(Serial 2 only)
0
1
OFF
ON
0 No
Example
Change baud rate of instrument 1 serial 1.
Command Response Details
S01; Select Instrument 1
BDR?0; 0,5,0,8,1,0,0,0 CRLF Query Baud Rate Setting
BDR0,3; 0 CRLF
Note: Reply is sent using the new
settings if using the changed port.
Settings changed to 2400 baud
TDD1; 0 CRLF Save New Settings
