Rinstrum - 5200 Communications Manual Rev 1.2
0025-605-120 Page 27
2.4.16. IAD: Set Scale Build
This is used to set the scale build parameters.
General Details
No. of Parameters Save Changes Changes Used Increment Trade Counter
8 With TDD1 Immediately Yes
Parameter Details
Parameter Description Range Default Required
1 Range 1 to 2 1 No
2 Nominal Load
(CAP1 or CAP2)
100 to 999999 CAP1: 3000
CAP2: 6000
No
3 Number of right side
digits (decimal point
position)
0 to 5 0 No
4 Resolution 1
2
3
4
5
6
7
1
2
5
10
20
50
100
E1: 1
E2: 2
No
5 x 10 mode 0
1
OFF
ON
0 No
6 Additive Tare 0 to fullscale 0 No
7 Interlock 0 to fullscale 20 No
8 Automatic Tare 0
1
OFF
ON
0 No
Note that the fullscale weight of the instrument is set to Nominal Load 1 for single
range installations, and Nominal Load 2 for dual-range and dual-interval
installations. In single range installations Nominal Load 2 is not used.
Example
Command Response Details
S01; Select Instrument 1
IAD?1; 1,3000,0,1,0,0,20,0 CRLF Query current scale build
parameters
IAD1,4000,1,2,0; 0 CRLF Range=Single, CAP1=4000,
Decimal Point position=1, E1=2,
x10 mode is off.
TDD1; 0 CRLF Save Setting
If IAD? is issued without the range parameter then the returned data is range 1 for
single range setup or range 2 for dual interval or dual range setup. In this way it is
possible to query the maximum load without the need to issue a WMD? Command
to determine the weighing mode.
