Rinstrum - 5200 Communications Manual Rev 1.2
0025-605-120 Page 15
2.4.6. CHK: Set Checkweigh (Catchweigh) Options
Set the checkweigh options.
General Details
No. of Parameters Save Changes Changes Used Increment Trade Counter
12 With TDD1 Immediately No
Parameter Details
Parameter Description Range Default Required
1 Trigger Option 0
1
Input trigger only
Weight and/or input
trigger
- No
2 Weight Trigger
Level
999999 to –999999 100 No
3 Weight Trigger
Reset Level
999999 to –999999 0 No
4 Pre-average
Delay
0 to 30000 (x0.01s) 100 No
5 Average time 0 to 30000 (x0.01s) 100 No
6 Display Option 0
1
2
Normal weight
display
Check weight display
Check grade display
0 No
7 Display Timeout 0 to 30000 (x0.01s) 300 No
8 to 12 No Grade
Name,
Grade 1 Name
to Grade 4
Name
6 character string “G0” to
“G4”
No
Example
Set trigger option to weight trigger.
Command Response Details
S01; Select Instrument 1
CHK?; 0,100,0,100,100,0,300,"G0","G1",
"G2","G3","G4" CRLF
Query checkweigh settings
CHK1; 0 CRLF Trigger changed to weight
TDD1; 0 CRLF Save New Settings
