PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
3-56 Programming and Parameters
UTILITY
User Defined
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
[UsrDefBitWrdA0]
[UsrDefBitWrdA1]
[UsrDefBitWrdA2]
[UsrDefBitWrdA3]
[UsrDefBitWrdA4]
[UsrDefBitWrdA5]
[UsrDefBitWrdA6]
[UsrDefBitWrdA7]
[UsrDefBitWrdA8]
[UsrDefBitWrdA9]
[UsrDefBitWrdA10]
[UsrDefBitWrdA11]
[UsrDefBitWrdA12]
[UsrDefBitWrdA13]
[UsrDefBitWrdA14]
[UsrDefBitWrdA15]
Bit variables. The individual "User Defined" bits can be read or written
to. It is possible to process a word with Par 519 [UsrDefBitWrdA] (see
example).
Note: You can read bits 0-7 of a digital input with Par 519
[UsrDefBitWrdA] and write all of the bits associated with
[UsrDefBitWrdA] to a digital output.
Default:
Min/Max:
0
0 / 1
519
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
A
