Audio Operations
Adjusting the USB Audio Signal
This congures the output level, equalizer and mastering eects for
the STREAMING port audio.
1. Select Root menu “Processing” 0 “USB Streaming” 0
“Audio,” “Equalizer,” “Mastering” parameters.
2. Turn the [VALUE] knob to set the parameter.
Parameter Explanation
Delay
If there is a timing discrepancy between the
video and audio, you can correct the output
timing by delaying the audio output.
Level Adjusts the output level.
Equalizer Enables/disables the equalizer.
Hi Freq
Species the center frequency when
changing the tone quality in the high band.
Gain Boosts or attenuates the high band.
Mid Q
Adjusts the width of the frequency band
when boosting or attenuating the middle
band.
Freq
Species the center frequency when
changing the tone quality in the middle band.
Gain Boosts or attenuates the middle band.
Low Freq
Species the center frequency when
changing the tone quality in the low band.
Gain Boosts or attenuates the low band.
Mastering Enables/disables the mastering.
Enhancer Adjusts the audio clarity.
Sense
Adjusts how much the mastering eects are
applied.
Level Adjusts the volume of the mastered sound.
3. Press the [SETUP] button twice to return to the Root
menu screen.
Setting the Output Destination of the Analog
Audio Signal
This sets the signal to output from the AUDIO IN/OUT connector and
LINE OUT jacks.
1. Select Root menu “Output” 0 “Analog Audio” 0
“Assign.”
2. Turn the [VALUE] knob to set the output destination.
Value Explanation
SDI OUT CH. 1/2–15/16
Each channel of the 12G-SDI OUT
connector
HDMI OUT CH. 1/2–7/8
Each channel of the HDMI 4K OUT
connector
USB OUT CH. 1/2 STREAMING port
SDI IN CH. 1/2–15/16
Each channel of the 12G-SDI IN
connector
HDMI 2 CH MIX
Two channels are output, down
mixed with the audio from the
HDMI 4K IN connector.
USB IN CH. 1/2 STREAMING port
Analog IN CH. 1/2 LINE IN jacks
Analog IN CH. 3/4 AUDIO IN/OUT connector
Test Tone Outputs a test tone.
NONE Not assigned
3. Press the [SETUP] button twice to return to the Root
menu screen.
Conguring the Audio Output
