Setup Menu List
INPUT
SDI
Menu item (Parameter) Value (Bold: default) Explanation
Color Gamut
REC.601, REC.709, REC.2020, Auto Species the color gamut.
Dynamic Range
SDR, HDR PQ, HDR HLG, Auto Species the dynamic range.
HDMI
Menu item (Parameter) Value (Bold: default) Explanation
EDID
This selects the EDID to set in the built-in EDID emulator.
1080i/50.00
1080i/59.94/60.00
1080p/50.00
1080p/59.94/60.00
1080p/119.88/120.00
1080p/239.76/240.00
2160p (UHD)/50.00
2160p (UHD)/59.94/60.00
2160p (DCI)/50.00
2160p (DCI)/59.94/60.00
1280 x 1024/60
1920 x 1200/60RB
2560 x 1440/60RB
1920 x 1080/120RB
1920 x 1080/144RB (346.5)
1920 x 1080/240RB (556.8)
1920 x 1080/240RB (567.0)
Default
Color Gamut
REC.601, REC.709, REC.2020, Auto Species the color gamut.
Dynamic Range
SDR, HDR PQ, HDR HLG, Auto Species the dynamic range.
Color Space
Auto, YUV422, YUV444, RGB Full,
RGB Limit
Sets the color space.
Pattern Generator
Menu item (Parameter) Value (Bold: default) Explanation
Pattern
Disabled, Color Bars, Color Sweep,
H Ramp, V Ramp, HV Ramp, Hatch,
Checker, Red, Green, Blue, Black,
White
Selects the test pattern.
Motion
Disabled, Slow, Fast Sets how fast the motion test pattern moves.
Analog Audio
Menu item (Parameter) Value (Bold: default) Explanation
Level CH. 1/2
0–100–127 Adjusts the volume of audio from the LINE IN jacks.
Level CH. 3/4
0–100–127 Adjusts the volume of audio from the AUDIO IN/OUT connector.
