Roland VC-100UHD User Manual

30
Setup Menu List
Output
SDI
Menu item (Parameter) Value (Bold: default) Explanation
Source Processing
Main, Sub Sets the processing system output from the 12G-SDI OUT connector.
3G-SDI Mapping
Level A, Level B Sets the mapping of the 3G-SDI output.
HDMI
Menu item (Parameter) Value (Bold: default) Explanation
Source Processing
Main, Sub Sets the processing system output from the HDMI 4K OUT connector.
Signal Type
HDMI, DVI-D Sets the standard used for the output signal.
Color Space
Auto, YUV422, YUV444, RGB Full,
RGB Limit
Sets the color space used during output.
Audio Channel
2CH, 5.1CH, 7.1CH Sets the maximum number of audio channels used during output.
Input Through
Disabled, Enabled
When this is set to “Enabled,” signals input through the HDMI 4K IN connector
are output as-is from the HDMI 4K OUT connector.
* When “Input Through” is set to “Enabled,” set “Sub Processing” (p. 24) to
“Disabled.”
Analog Audio
Menu item (Parameter) Value (Bold: default) Explanation
Assign
Sets the output destination for the analog audio signal.
SDI OUT CH. 1/2–15/16
Each channel of the 12G-SDI OUT connector
HDMI OUT CH. 1/2–7/8
Each channel of the HDMI 4K OUT connector
USB OUT CH. 1/2–15/16
STREAMING port
SDI IN CH. 1/2–15/16
Each channel of the 12G-SDI IN connector
HDMI 2 CH MIX
Two channels are output, down mixed with the audio from the HDMI 4K IN
connector.
USB IN CH. 1/2
STREAMING port
Analog IN CH. 1/2
LINE IN jacks
Analog IN CH. 3/4
AUDIO IN/OUT connector
Test Tone
Outputs a test tone.
None
Not assigned
Delay
0.0–16.0fs (frames)
Adjusts the audio delay time. Delays the output of the audio by the specied
time.
Level
0–100–127 Adjusts the output level.
Equalizer
Disabled, Enabled
Enables/disables the equalizer.
Hi Freq
20–10k–20k
Species the center frequency when changing the tone quality in the high band.
Hi Gain
-12–0.0–+12
Boosts or attenuates the high band.
Mid Q
0.3–1.0–16
Adjusts the width of the frequency band when boosting or attenuating the
middle band.
Mid Freq
20–1.25k–20k
Species the center frequency when changing the tone quality in the middle
band.
Mid Gain
-12–0.0–+12
Boosts or attenuates the middle band.
Low Freq
20–1.25k–20k
Species the center frequency when changing the tone quality in the low band.
Low Gain
-12–0.0–+12
Boosts or attenuates the low band.
Mastering
Disabled, Enabled
Enables/disables the mastering.
Enhancer
-24–0–-12dB
Adjusts the audio clarity.
Sense
0–24
Adjusts how much the mastering eects are applied.
Level
-24–0dB
Adjusts the volume of the mastered sound.
