Setup Menu List
System
Frame Rate
Menu item (Parameter) Value (Bold: default) Explanation
Frame Rate
50.00 Hz, 59.94 Hz, 60.00 Hz
Sets the system’s frame rate.
The congurable formats change for each processing system.
Genlock
Menu item (Parameter) Value (Bold: default) Explanation
Source
This sets the genlock source.
Internal Sets the source to internal sync (free-run).
External Syncs to the analog external sync signal input to the REFERENCE IN connector.
SDI Syncs to the input from the 12G-SDI IN connector.
About the output from the REFERENCE THRU/OUT connector
When this unit is operating with sync set to “Internal” or “SDI,” the sync signal inside the unit is output as a black burst.
When this unit is operating with sync set to “External” or “SDI,” the external sync input is output as-is.
Line Adjust
-2160–0–+2160 Corrects delays in the genlock line.
HDCP
Menu item (Parameter) Value (Bold: default) Explanation
HDCP
Disabled, Enabled
If this is set to “Enabled,” copy-protected (HDCP) video can be input. Also, HDCP
is applied to the video that is output.
* If this is set to “Enabled,” video is not output from the 12G-SDI OUT connector
and STREAMING port.
Fade Time
Menu item (Parameter) Value (Bold: default) Explanation
Fade Time
0.0s–0.5s–1.0s Sets the fade time.
Orientation
Menu item (Parameter) Value (Bold: default) Explanation
Orientation
Center, Top Left Sets the reference point when scaling.
Panel Lock
Menu item (Parameter) Value (Bold: default) Explanation
Panel Lock
Disabled, Enabled
Enables/disables the panel lock function.
When this is set to “Enabled,” the panel automatically locks (the display goes
dark) when it is not operated for at least one minute.
Hold down the [SETUP] button to unlock the panel.
