Connection
―
Ensure you connect each of the adapters to the correct RS232C IN or OUT port on the product.
•
Connection 1 (EDE / EME Model)
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
•
Connection 2 (DCE / DCE-M / DCE-H Model)
RJ45 RJ45
•
Connection 3 (DCE / DCE-M / DCE-H Model)
RS232C
IN
