Sanyo PLV-Z5 Service Manual

-60-
Group: 0 ADV7403
0 SOG_SYNC_LEV 11/11/11/11/11/11/11 0 - 31 PC/480i/575i/480p/575p/720p/1080i
Group: 3 L3E06150/1060P0A (Panel Driver)
0 G_LCCOM 300 0 - 511 ✻ G Common center adjustment
1 B_LCCOM 300 0 - 511 ✻ B Common center adjustment
2 R_LCCOM 300 0 - 511 ✻ R Common center adjustment
3 G_LCCOM_GAIN 191 0 - 255 G Signal Gain
4 B_LCCOM_GAIN 191 0 - 255 B Signal Gain
5 R_LCCOM_GAIN 191 0 - 255 R Signal Gain
6 G_LCCOM_BRIGHT 0 0 - 255 G Signal Bright
7 B_LCCOM_BRIGHT 0 0 - 255 B Signal Bright
8 R_LCCOM_BRIGHT 0 0 - 255 R Signal Bright
9 G_VIDEO_CENTER 18 0 - 63 G Video Center
10 B_VIDEO_CENTER 18 0 - 63 B Video Center
11 R_VIDEO_CENTER 18 0 - 63 R Video Center
12 R_ENBX_PW 12 0 - 255 R ENBX pulse width
13 G_ENBX_PW 12 0 - 255 G ENBX pulse width
14 B_ENBX_PW 12 0 - 255 B ENBX pulse width
15 R_DXIN 2 0 - 255 R DXIN Delay
16 G_DXIN 2 0 - 255 G DXIN Delay
17 B_DXIN 2 0 - 255 B DXIN Delay
18 R_CLXIN 2 0 - 255 R CLXIN Delay
19 G_CLXIN 2 0 - 255 G CLXIN Delay
20 B_CLXIN 2 0 - 255 B CLXIN Delay
21 R_ENBX1IN 14 0 - 255 R ENBX1IN Delay
22 G_ENBX1IN 14 0 - 255 G ENBX1IN Delay
23 B_ENBX1IN 14 0 - 255 B ENBX1IN Delay
Group: 4 L3E07110K0A (Digital Gamma)
0 G_Contrast 512/512/512 360 - 535
1 B_Contrast 512/512/512 360 - 535 PureCinema/BrilliantCinema&CreativeCinema&Natural&Living/Dynamic&Vivid
2 R_Contrast 512/512/512 360 - 535
3 G_Bright 0/0/0 0 - 1023
4 B_Bright 0/0/0 0 - 1023
5R_Bright 0/0/0 0 - 1023
6 G_Gamma_Shift 0/0/0 -512 - 511 ✻ Panel luminance adjustment
7 B_Gamma_Shift 0/0/0 -512 - 511 ✻ White balance adjustment [B]
8R_Gamma_Shift 0/0/0 -512 - 511 ✻ White balance adjustment [R]
9 R_REF_H 1023 0 - 1023
10 R_REF_L 336 0 - 1023
11 G_REF_H 1023 0 - 1023
12 G_REF_L 336 0 - 1023
13 B_REF_H 1023 0 - 1023
14 B_REF_L 336 0 - 1023
15 DXOUTR 214 0 - 1023
16 DXOUTG 214 0 - 1023
17 DXOUTB 214 0 - 1023
18 ENBX_R 0 0 - 127
19 ENBX_G 0 0 - 127
20 ENBX_B 0 0 - 127
21 H_CHANGE_Pos 6 0 - 255
22 SH_BASE_Pos 0 0 - 1
23 R_SH_Pos 10 0 - 15
24 G_SH_Pos 10 0 - 15
25 B_SH_Pos 10 0 - 15
26 NRG_Pos 51 0 - 127
27 NRG_Width 48 0 - 255
28 OSD_Pos 2 0 - 3
29 OSD_Pat 0 0 - 7
30 Gamma_Ctrl 1 0 - 1
31 REF_GATE_Pos 1 0 - 1023
32 REF_GATE_Width 180 0 - 1023
33 R_BASE_Pos 6 0 - 15
34 G_BASE_Pos 6 0 - 15
35 B_BASE_Pos 6 0 - 15
36 RGB_ADJUST 0 0 - 7
37 RGB_ADJLEV 0 0 - 1023
38 LINE_R0 8 0 - 255
39 LINE_R1 4 0 - 255
40 LINE_R2 2 0 - 255
41 LINE_R3 0 0 - 255
42 LINE_R4 0 0 - 255
43 LINE_G0 8 0 - 255
44 LINE_G1 4 0 - 255
45 LINE_G2 2 0 - 255
46 LINE_G3 0 0 - 255
Electrical Adjustments
● Service Adjustment Data Table
These initial values are the reference data written from the CPU
ROM to memory IC when replaced new memory IC. The adjust-
ment items indicated with “✻” are required to readjust following
to the “Electrical adjustments”. Other items should be used with
the initial data value.
No. Adjustment Item Initial Value Range Input source / Description

Sanyo PLV-Z5 Specifications

General

Number of colors	1.073 billion colors
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Projector native resolution	1280x720
Keystone correction, vertical	± 20 °
Digital zoom	2 x
Zoom capability	Yes
Focal length range	21.3 - 42.6 mm
RS-232 ports	1
Compatibility	WXGA/SXGA/XGA/SVGA/VGA/MAC
Dimensions (WxDxH)	382 x 304.3 x 126.8 mm
Power requirements	100 - 240 V
Horizontal resolution	420 lines
Lamp type	UHP
Lamp power	145 W
Light source type	Lamp
Service life of light source	3000 h
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Display diagonal	0.7 \
Power consumption (typical)	185 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	5000 g
