2.5 Protection functions

3VA molded case circuit breakers with UL and IEC certification

64 Manual, 01/2019, L1V30435333-01

2.5.1

Description of functions

The protection function performed by the molded case circuit breaker in the power

distribution network is defined by the choice of trip unit. There are two different types of

trip unit, i.e. thermal-magnetic (TMTU) and electronic (ETU):

Manual, 01/2019, L1V304353333
