Commissioning the device
4.1 Overview
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
67
Front operator controls
Touch HMI device
You can operate the Touch HMI devices with the touch screen. All operating elements
required for operation are displayed on the touch screen once the HMI device has been
started.
Damage to the touch screen
Pointed or sharp objects, abrupt contact, and continuous gesture operation can significantly
reduce the life of the touch screen and possibly lead to total failure of the touch screen.
• Do not touch the touch screen with pointed or sharp objects.
• Avoid contacting the touch screen abruptly with hard objects.
• Avoid continuous operation of the touch screen with gestures.
Triggering unintended actions
Touching several operating elements at the same time can trigger unintended actions.
Touch only one operating element on the screen at a time.
You operate the key HMI devices using the system keys and the function keys. The
functions of the function keys are defined during configuration. The function keys have no
function before the project is opened in the HMI device.
