Page #157 background image
Parameters
4.3 Monitoring functions
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
157
Settings
Table 4- 47 "Temperature monitoring" settings
Temperature
Description
Trip level T >
-273° - 65262°C (default: -273°)
Response to trip level T > Setting of response when the temperature is overshot (see the
following table and Chapter Important information (Page 7))
Marking for trip level T > No parameters. Optional marking for identifying the message,
e.g. "Temperature>"; range: Maximum 10 characters
Warning level T >
-273° - 65262°C (default: -273°)
Response to warning level T > Setting of response when the temperature is overshot (see the
following table and Chapter Important information (Page 7))
Marking warning level T > No parameters. Optional marking for identifying the message,
e.g. "Temperature>"; range: maximum 10 characters.
Hysteresis
to 255°C in steps of 1°C (default: 5°C)
Trip level activity, warning level
The trip level / warning level is always active, independent of whether the motor is running or
not (operating state "ON").
