Note
Original packaging
Keep the packaging of components with permanent magnets where possible!
When reusing the original packaging do not cover safety instructions that are possibly attached.
When required, use transparent adhesive tape for the packaging.
4.2 Transporting and storage
Note
UN number for permanent magnets
UN number 2807 is allocated to permit magnets as hazardous item.
NOTICE
Damage to the motor when incorrectly lifted
Improper use of lifting devices can cause plastic deformation of the motor.
• To lift the motor (or stator/rotor), at least three lifting eyebolts are required.
• Screw the lifting eyebolts symmetrically into the tapped holes on the at motor (or stator/
rotor).
• Only lift motors (or stators/rotors) when they are in a horizontal position.
• The lifting ropes must be the same length. The tightened lifting ropes must form an angle
of at least 50° between the lifting rope and motor (or stator/rotor).
WARNING
Risk of toppling over
Motors, stators, and rotors must not be stacked too high – risk of death, personal injury and/or
material damage.
• Never stack packed or unpacked motors, stators or rotors on top of one another.
• Only transport and store motors, stators and rotors in the horizontal position.
• Observe the safety instructions and handling on the packaging.
The rotor is secured in the stator by means of transport locks, and is protected by spacer lm. The
original packaging for the built-in torque motor and the transport locks (incl. the screws) are
required for storage/transport purposes and should, therefore, be kept in a safe place.
Preparation for use
4.2Transporting and storage
1FW6 built-in torque motors
Operating Instructions, 09/2022, A5E52220812B AA 61
