6.4 CBE30-2 Ethernet communication board
SIMOTION D4x5-2
108 Manual, 02/2012
6.4.2 Type plate
Type plate
The figure below contains all the information included on the type plate.
+DUGZDUHYHUVLRQ
0RGXOHGHVLJQDWLRQ
6HULDOQXPEHU
2UGHU1R
&7LFN
F8/XV
Figure 6-8 CBE30-2 type plate
You might need to access the information provided on the type plate after mounting.
Because the type plate is located on the under side of the CBE30-2, we recommend that you
note the serial number before installing it.
Note
The contents of the individual type plate fields of the CBE30-2 may differ from those
described in this manual (e.g. updated product status, approvals and markings not yet
issued, etc.).
MAC address
A second plate for the MAC address of the PROFINET interfaces is attached to the top side
of the board:
MAC address
Figure 6-9 CBE30-2 MAC address
This plate is only visible when the CBE30-2 has been removed. You need the MAC address
to assign an IP address.
Note
The MAC address is affixed to the top side of the CBE30-2, behind the RJ45 sockets.
