Supplementary system components
6.5 CX32-2 controller extension
SIMOTION D4x5-2
Manual, 02/2012
117
6.5.2.2 List of interfaces
The CX32-2 has the following interfaces:
● 4 DRIVE-CLiQ interfaces
● 4 digital inputs/outputs
● 6 digital inputs
● Power supply connector
Available interfaces
Table 6- 19 Overview of available interfaces
Interface Designation Connector type
DRIVE-CLiQ interface X100 DRIVE-CLiQ socket
DRIVE-CLiQ interface X101 DRIVE-CLiQ socket
DRIVE-CLiQ interface X102 DRIVE-CLiQ socket
DRIVE-CLiQ interface X103 DRIVE-CLiQ socket
Digital inputs/outputs X122 Mini Combicon, 3.5 mm,
1x14-pin
Power supply connector X124 Combicon, 4-pin
Measuring sockets (T0, T1, T2, and M) X131 - X134 Sockets
Non-usable interfaces
Table 6- 20 Overview of interfaces that cannot be used for the CX32-2
Interface name Interface Connector type
RS232 interface X140 9-pin Sub-D connector
