SIMOTION D4x5-2
Manual, 02/2012
87
Dimension drawings
5
5.1 D425-2 and D435-2 dimension drawing












Figure 5-1 D425-2 and D435-2 dimension drawing
SIMOTION D425-2 DP, D425-2 DP/PN, D435-2 DP and D435-2 DP/PN must always be
operated with a double fan/battery module.
NOTICE
The 80 mm clearances above and below the components must be observed. The unit
protects itself from overheating by shutting down.
