SIMOTION D4x5-2
Manual, 02/2012
47
Interfaces
3
3.1 Interface overview
This section describes the interfaces of the SIMOTION D4x5-2.
The position of the interfaces on the module can be found in the following sections:
● Representation of SIMOTION D425
-2 DP and D435-2 DP (Page 22)
● Representation of SIMOTION D425-2 DP/PN and D4
35-2 DP/PN (Page 24)
● Representation of SIMOTION D445-2 DP/PN and D4
55-2 DP/PN (Page 26)
Available interfaces
Table 3- 1 Overview of available interfaces
Interface Designation Connector type
DRIVE-CLiQ interface X100 DRIVE-CLiQ socket
DRIVE-CLiQ interface X101 DRIVE-CLiQ socket
DRIVE-CLiQ interface X102 DRIVE-CLiQ socket
DRIVE-CLiQ interface X103 DRIVE-CLiQ socket
DRIVE-CLiQ interface
(not for SIMOTION D425-2)
X104 DRIVE-CLiQ socket
DRIVE-CLiQ interface
(not for SIMOTION D425-2)
X105 DRIVE-CLiQ socket
Ethernet interface PN/IE X127 P1 RJ45 socket connector
PN/IE OP Ethernet interface
(only for SIMOTION D4x5-2 DP)
X120 P1 RJ45 socket connector
Ethernet interface PN/IE-NET X130 P1 RJ45 socket connector
PROFINET PN IO interface
(only for SIMOTION D4x5-2 DP/PN)
X150 (P1, P2, P3) RJ45 socket connector
Digital I/Os X122, X132, X142 Mini Combicon, 3.5 mm
3x14-pin
Power supply connector X124 Combicon, 4-pin
PROFIBUS DP interface X126 9-pin Sub-D socket
PROFIBUS DP/MPI interface X136 9-pin Sub-D socket
Measuring sockets (T0, T1, T2, and M) X141 4-pin, socket
SIMOTION CF plug-in X109 CompactFlash card connector
Fan/battery module interface X190/X191 Fan/battery module
