Interfaces
3.8 Slot for CompactFlash card
SIMOTION D4x5-2
Manual, 02/2012
69
3.8 Slot for CompactFlash card
Characteristics
Connector type: 50-pin connector
This interface should only be used to insert a special SIMOTION CompactFlash card
(CF card).
&RYHU
6ORWZLWKLQVHUWHG&)FDUG
Figure 3-9 Slot for the CompactFlash card
Consult the relevant references for detailed information about the SIMOTION CompactFlash
card in Section CompactFlash card (Page 33).
